STPS15L60CB is a 2A power Schottky rectifier suited for Switch Mode Power Supply and high frequency DC to DC converters. Packaged in DPAK, this device is intended for use low voltage, high frequency inverters, free-wheeling and polarity protection applications.
The STPS15L60CB Schottky rectifier is designed for switch‑mode power supplies and high‑frequency DC‑DC converters. Its dual center‑tab DPAK package makes it suitable for low‑voltage, high‑frequency inverters, free‑wheeling and polarity‑protection applications.
Key electrical characteristics include a repetitive peak reverse voltage of 60 V, an average forward current of 7.5 A (up to 15 A at higher temperature), and a low forward voltage drop of 0.52 V at 125 °C. Thermal performance features a junction‑to‑case resistance of 4 °C/W and a surge non‑repetitive forward current of 75 A for 10 ms pulses.
| Repetitive peak reverse voltage (VrRM) | 60 V |
|---|---|
| Surge non‑repetitive forward current | 75 A (10 ms) |
| Junction‑to‑case thermal resistance (RθJC) | 4 °C/W |
| Package type | DPAK |
The device is rated for a repetitive peak reverse voltage of 60 V.
It can sustain a non‑repetitive surge forward current of 75 A for a 10 ms pulse.
The rectifier is supplied in a DPAK (TO‑252) surface‑mount package.
