3M Iron Man Workstation Monitors can protect sensitive circuit boards from overvoltage and electrostatic discharge. Suitable for electronics assembly, repair and service, medical environment, military aerospace and other places where sensitive components are handled.
The Iron Man™ Workstation Monitors (CTC330 and CTC331) protect sensitive electronic assemblies from over‑voltage and electrostatic discharge. They monitor board voltage, operator wrist‑strap connectivity, body voltage, and dissipative mat grounding, providing immediate audio and visual alarms when limits are exceeded.
The guide details the monitor’s features, installation of the monitor lead and grounding hardware, alarm thresholds, dimensions, power requirements, and ordering information. It also includes safety notices, warranty terms, and a parts list for accessories such as wrist‑strap jacks and ground cords. This manual is written in Chinese.
| Overvoltage Alarm Threshold Range | 0…±5 V ; 0…±50 V |
|---|---|
| Operator Body Voltage Alarm | Yes |
| Wrist‑strap Connector | Dual, 3.5 mm plug |
| Dimensions (CTC330) | 2.4 W × 0.85 H × 1.63 L inches |
| Power Supply | External adapter |
The monitor is powered by an external power adapter.
The CTC330 measures 2.4 inches wide, 0.85 inches high, and 1.63 inches long.
