This PDF file is an product promotion document for Omron EE-SX670 series photomicrosensors.
The EE‑SX47/67 series are photomicrosensors with built‑in amplifiers, offering both dark‑ON and light‑ON operation. They provide a wide operating voltage range (5‑24 VDC) and a response frequency up to 1 kHz, making them suitable for industrial automation and robot cable applications.
The document lists ordering information for standard, pre‑wired and junction‑connector models, details mechanical dimensions, environmental ratings (IP50, –25 °C to +55 °C), and safety precautions for installation and soldering. Warranty, liability and usage guidelines are also included.
| Supply voltage | 5 to 24 VDC |
|---|---|
| Current consumption (NPN) | 35 mA max |
| Enclosure rating | IP50 (IEC60529) |
| Ambient temperature range | -25 °C to +55 °C (operating) |
| Sensing distance | 5 mm (slot width) |
They operate from 5 VDC up to 24 VDC.
No, they have an IP50 rating and are not water‑proof; they should not be exposed to splashes.
