LM3S6965 Microcontroller data sheet. This microcontroller is produced by Luminary Micro.
This datasheet describes the LM3S6965 ARM Cortex‑M3 based microcontroller, covering its architecture, peripheral set, and memory map. It includes block diagrams, functional overviews, and detailed register descriptions for each module.
The document also contains ordering information, package options, and contact details for Luminary Micro support, helping engineers select the correct part variant and obtain evaluation kits.
| Package – 48‑pin LQFP | QN = 48‑pin LQFP revision |
|---|---|
| Package – 100‑pin LQFP | QC = 100‑pin LQFP |
| Maximum Core Frequency | 20 MHz |
| Maximum Core Frequency (higher speed) | 25 MHz |
| Maximum Core Frequency (top speed) | 50 MHz |
The part numbers are LM3S6965‑1QC50 and LM3S6965‑IQC50(T).
Evaluation kits are available from Luminary Micro’s website under the Evaluation Kits section.
Support can be reached via email at [email protected] or by phone at +1‑512‑279‑8800 ext. 3.
