LM3S817 is a microcontroller produced by Luminary Micro
This datasheet describes the LM3S817 microcontroller, an ARM Cortex‑M3‑based MCU from Luminary Micro. It includes an architectural overview, high‑level block diagrams, and detailed descriptions of motor‑control, analog, serial, and system peripherals.
The document also contains electrical characteristics, package information, ordering details, and a complete register map for developers. Contact and support information for Luminary Micro is provided at the end of the file.
| Maximum core frequency | 50 MHz |
|---|---|
| Package type (SOIC) | 28‑pin SOIC |
| Package type (LQFP) | 48‑pin LQFP |
| Package type (LQFP, 100‑pin) | 100‑pin LQFP |
| Part number for 48‑pin LQFP version | LM3S817‑IQN50 |
The part number is LM3S817‑IQN50.
Support is provided by Luminary Micro, Inc.
The datasheet is dated November 29 2007.
