MAX3341E is a USB level translator that converts logic-level signals to USB signals and USB signals to logic-level signals.
The MAX3341E USB level translator converts logic‑level signals to USB signals and vice‑versa, offering built‑in +15 kV ESD protection on the D+ and D‑ pins. It operates from low logic supplies down to 1.8 V and supports full‑speed (12 Mbps) USB 2.0 operation. The device includes an internal 1.5 kΩ termination resistor, a linear regulator for 3.3 V output, and a USB detect function.
Available in a miniature 4 × 4 UCSP package and a 16‑pin TSSOP, the MAX3341E is specified over –40 °C to +85 °C and can handle up to +15 mA continuous current on all pins. Detailed electrical characteristics, timing specifications, and pin descriptions are provided for designers.
| Supply Voltage (Vcc) | -0.3 V to +6 V |
|---|---|
| Maximum Continuous Current (all other pins) | +15 mA |
| Operating Temperature Range | -40 °C to +85 °C |
| ESD Protection (D+ and D‑) | +15 kV |
| USB Data Rate | 12 Mbps (full‑speed) |
| Package Types | 4 × 4 UCSP, 16‑pin TSSOP |
The MAX3341E provides +15 kV ESD protection on both D+ and D‑ pins.
It is specified for operation from –40 °C to +85 °C.
The supply voltage (Vcc) can be between –0.3 V and +6 V.
All pins can handle up to +15 mA continuous current.
