The MAX2338 is a dual-band CDMA cellular phone receiver RF front-end IC designed by Texas Instruments, and it can also be used in dual-band TDMA, GSM, or EDGE cellular phones. Thanks to the MAX2338's on-chip low-power LO divider, the cellular VCO module can be eliminated. The MAX2338 includes a low-noise amplifier (LNA) with an adjustable high-input third-order intercept point (IIP3) to minimize intermodulation and cross-modulation in the presence of large interfering signals. For cellular band operation, a low-gain LNA is available for higher cascaded IIP3 at lower current. The CDMA mixers are designed for high linearity, low noise, and differential IF outputs. The FM mixer is designed for lower current and single-ended output. The MAX2338 triple-mode LNA/mixer includes an on- chip LO frequency divider to allow the use of a single VCO for both bands. This device is available in an ultra- small 28-pin leadless QFN package.
The MAX2338 is a receiver RF front‑end IC designed for dual‑band CDMA cellular phones, also usable in dual‑band TDMA, GSM, or EDGE phones. It integrates a low‑noise LNA, on‑chip LO divider, and mixers with high linearity, all in an ultra‑small 28‑pin leadless QFN package.
The document includes absolute maximum ratings, DC and AC electrical characteristics, typical operating curves, pin functions, S‑parameter tables for cellular and PCS band mixers, and package information, enabling designers to evaluate and implement the device in RF front‑end circuits.
| LNA Noise Figure | 1.4 dB |
|---|---|
| LNA Gain | 15 dB |
| Mixer Noise Figure (CDMA) | 7.5 dB |
| LO Frequency Divider | Integrated on‑chip |
| Package | 28‑pin leadless QFN |
It is supplied in an ultra‑small 28‑pin leadless QFN package.
The LNA noise figure is 1.4 dB.
The maximum storage temperature is 1 V peak.
