TLP150-M Series is a single output switch power supply launched by Dinghao. The rated power is 150W, the input voltage range is 85-264VAC, and it supports single-phase input. It has 12V fan output and 5V standby output.
The TLP150-M Series is a 150 W embedded power module designed for business‑critical continuity. It accepts a universal AC input of 85‑264 VAC, offers active power factor correction, and includes over‑current, over‑voltage, over‑temperature and short‑circuit protection. Optional 5 V standby output and a 12 V fan output are available, and the unit complies with EN61000‑3‑2, EN55022‑B, UL2601‑1 and other safety standards.
The module is offered in single‑output configurations with a maximum output of 13.15 A at 250 VAC. It can be cooled by forced‑air (200 LFM) for full‑power operation or by natural convection for lower loads. Mechanical dimensions, connector options (Molex, Leoco, JST, etc.) and environmental limits are detailed in the datasheet.
| Total Power | 150 W |
|---|---|
| Input Voltage Range | 85‑264 VAC |
| Input Frequency Range | 47‑63 Hz |
| Output Current | 13.15 A, 250 VAC |
| Efficiency @115 VAC, 150 W | 81 % typ. |
| Efficiency @230 VAC, 150 W | 84 % typ. |
| Weight | 260 g (9.2 oz) |
| MTBF | 900,000 hours min. |
| Non‑operating Temperature Range | -40 °C to +85 °C |
| Maximum Operating Altitude | 10,000 ft |
The module accepts a universal AC input from 85 VAC to 264 VAC.
Yes, an optional 5 V standby output is available whenever AC input is present.
It includes over‑current, over‑voltage, over‑temperature, short‑circuit protection and complies with EN55022‑B and UL2601‑1 safety standards.
