The Fujitsu M3096G/H image scanner operator's guide provides step‑by‑step instructions for unpacking, configuring, and using the scanners. It describes the parts, indication panel functions, and how to connect the device to a host computer.
The manual also includes maintenance procedures, troubleshooting tips, and a full specification table for both models, including dimensions, weight, power requirements and environmental limits.
| Dimensions (W x D x H) – M3096H | 659 mm × 497 mm × 109 mm |
|---|---|
| Weight – M3096G | 27 kg (59.6 lb) |
| Weight – M3096H | 22 kg (48.6 lb) |
| Input voltage (North America) | 100‑120 VAC |
| Input voltage (Europe) | 200‑240 VAC |
| Number of phases | Single phase |
| Frequency | 50/60 Hz |
| Power consumption (North America) | 2.2 A |
| Operating temperature range | 5 °C to 35 °C |
| Operating humidity range | 20 % to 80 % |
The M3096G can scan sheets of paper up to A3 and double‑letter size.
Only the M3096G model includes an automatic document feeder.
The scanner consumes 2.2 A when powered from 100‑120 VAC in North America.
The M3096H weighs 22 kg (48.6 lb).
