This manual introduces the functions and usage of the TSC TSP600 series thermal printer.
This manual covers safety and regulatory information, parts identification, consumable specifications, and installation steps for the TSP600 thermal printer. It explains how to connect the printer, select the proper AC adapter, load roll paper, and configure dip switches.
Operational guidance includes using the control panel, adjusting the near‑end sensor, preventing and clearing paper jams, and performing periodic cleaning of the thermal head. Appendices list detailed specifications, interface wiring, and memory switch settings.
| Roll paper thickness | 65~85 µm |
|---|---|
| Roll paper width | 79.5 ± 0.5 mm |
| Outer roll diameter | ≤ 690 mm |
| Optional AC adapter model | PS60-24 A |
| AC adapter input voltage | 100‑240 V AC, 50/60 Hz |
| AC adapter output | DC24 ± 5 % 2.0 A (5.0 A max 10 s) |
Use thermal paper with a thickness of 65‑85 µm and a width of 79.5 ± 0.5 mm; the outer roll diameter must be 690 mm or less.
The optional AC adapter (model PS60‑24 A) accepts 100‑240 V AC at 50/60 Hz and provides a DC24 ± 5 % output at 2.0 A (up to 5.0 A for 10 seconds).
Place the printer on a firm, level surface away from vibration, keep the surrounding area clean and dry, and use only the specified consumable parts and AC adapter.
Refer to the Periodical Cleaning section of the manual and follow the instructions for cleaning the thermal head.
