This document is the user manual for TSP400Z series thermal printers, providing instructions on how to use the printer and its features.
This manual guides users through unpacking, inspecting, and identifying the parts of the TSP400Z Series thermal printer. It includes handling notes, ferrite‑core installation for European models, and detailed instructions for connecting serial or parallel interface cables.
Later sections cover printer setup, control‑panel functions, DIP‑switch and memory‑switch settings, and full technical specifications. Appendices provide serial and parallel interface details, peripheral‑unit drive circuitry, and factory memory‑switch codes.
| Memory Switch 0 (hex) | 0000 |
|---|---|
| Memory Switch 2 (hex) | 0100 |
The printer supports both serial and parallel interface cables.
A ferrite core must be installed only on printers marketed in Europe.
The factory settings are listed in Appendix F as a table of hexadecimal codes for each switch.
