The LM358 is a dual differential‑input operational amplifier offering low power drain, single‑supply operation from 3.0 V to 32 V, and input ranges that include the negative supply. It is pin‑compatible with the MC1558 and provides short‑circuit protected outputs.
The datasheet lists detailed electrical characteristics such as supply voltage range, input bias current, power‑supply rejection ratio, and maximum output short‑circuit current, and includes representative circuit schematics and typical application examples like function generators and filter circuits.
| Supply Voltage Range | 3.0 V to 32 V |
|---|---|
| Input Bias Current | 45 – 250 pA |
| Power Supply Rejection Ratio (PSRR) | 65 – 100 dB |
It operates from 3.0 V up to 32 V on a single supply.
Yes, it can be used with split supplies up to ±16 V.
The input bias current is specified as 45 – 250 pA.
