LM224K / LM324K / LM2902K / LM224KA / LM324KA / LM2902KV / LM2902KAV is a four independent high gain frequency compensated operational amplifiers with 2 kV ESD protection, wide supply ranges and low supply current consumption, which can be powered by single or split supplies.
The LM124/LM124A, LM224/LM224A, LM324/LM324A and LM2902/LM2902V families are quadruple operational amplifiers designed for a wide supply range (3 V to 32 V) and low supply‑current drain. They are suitable for transducer amplifiers, DC amplification blocks and conventional op‑amp circuits, and can operate from a single 5‑V supply in digital systems.
The document provides detailed ordering information for various package types (PDIP, SOIC, SOP, TSSOP, etc.), absolute maximum ratings, electrical characteristics, mechanical dimensions, and an important notice covering warranty and usage restrictions.
| Maximum‑Rated Supply Voltage | 32 V |
|---|---|
| Input Offset Voltage | 3 mV Typ |
| Input Bias Current | 20 nA Typ |
Typical input offset voltage is 3 mV.
