The AD8310 is a high-precision, low-cost, single supply, 95 dB dynamic range, fast integrating logarithmic amplifier with voltage output. It can be used for RF signal detection, power measurement and signal processing applications.
The AD8310 is a complete, fast‑acting voltage‑output logarithmic amplifier that provides a 95 dB dynamic range from –91 dBV to +4 dBV. It operates from a single supply of 2.7 V to 5.5 V, draws only 8 mA quiescent current, and can source up to 25 mA into a grounded load in less than 15 ns.
Typical applications include conversion of signal level to decibel form, transmitter antenna power measurement, receiver signal strength indication, low‑cost radar and sonar processing, and spectrum analyzer front‑ends. The device is supplied in an 8‑lead MSOP package and is rated for –40 °C to +85 °C industrial temperature range.
| Dynamic Range | 95 dB |
|---|---|
| Supply Voltage | 2.7 V to 5.5 V |
| Input Capacitance | 14 pF |
| Maximum Output Current | 25 mA |
| Maximum Sink Current | 0.5 mA |
The AD8310 operates from a single supply voltage of 2.7 V to 5.5 V.
It can source up to 25 mA into a grounded load.
The device provides a 95 dB dynamic range from –91 dBV to +4 dBV.
