AD8314 is a low-cost RF signal measurement and control subsystem operating from 100 MHz to 2.7 GHz with a typical dynamic range of 45 dB, intended for use in a wide variety of cellular handsets and other wireless devices. It provides a wider dynamic range and better accuracy, rapid response time, low power consumption.
The AD8314 RF Detector/Controller integrates detection and control functions for wireless handsets and other devices. It operates from 100 MHz to 2.7 GHz, provides a linear‑in‑dB response, and consumes low power (12 mW at 2.7 V, 20 pA in power‑down).
The device offers two voltage outputs (V_UP for measurement and V_DN for control), selectable packages (8‑lead MSOP or LFCSP), and a range of pin functions for easy integration. Detailed specifications, absolute maximum ratings, and application notes are included in the document.
| Frequency Range | 0.1 – 25 GHz |
|---|---|
| Input Voltage Range | 1.25 – 224 mV rms |
| Supply Voltage (VPOS) | 2.7 V – 5.5 V |
| Quiescent Current | 3.0 mA – 5.7 mA |
| Response Time (10 %‑90 % for 10 dB step) | 70 ns |
| Available Output Current | 1 mA / 0.5 mA (source/sink) |
The AD8314 operates from 2.7 V to 5.5 V supply voltage.
Its 10 %‑90 % response time for a 10 dB step is 70 ns.
The device is offered in 8‑lead MSOP and 8‑lead LFCSP packages.
