This document is about ADV7184 technical data. ADV7184 is a multiformat SDTV video decoder that supports fast switch overlay support.
The ADV7184 is a single‑chip multiformat SDTV video decoder from Analog Devices that automatically detects and converts NTSC, PAL, and SECAM signals from composite, S‑Video, or component sources into digital ITU‑R BT.656 4:2:2 video.
The device integrates four 10‑bit ADCs, a 5‑line adaptive comb filter, and supports fast‑blank SCART overlay, macrovision detection, and VBI data recovery. It runs from a 28.63636 MHz crystal, uses 3.3 V analog and 1.8 V digital core supplies, and is packaged in an 80‑lead LQFP rated for –40 °C to +85 °C.
| Supported video input formats | Composite (CVBS), S‑Video (Y/C), YPrPb component (VESA, MII, SMPTE, Betacam) |
|---|---|
| ADC resolution | 10‑bit |
| Clock frequency | 28.63636 MHz crystal |
| Operating temperature range | -40 °C to +85 °C |
| Package type | 80‑lead LQFP (Pb‑free) |
| Number of analog input channels | 12 |
| Digital output format | ITU‑R BT.656 YCrCb 4:2:2 |
It supports NTSC (J, M, 4.43), PAL (B/D/G/H/I/M/N) and SECAM standards.
The device is rated for –40 °C to +85 °C.
The ADV7184 provides 12 analog video input channels.
It is supplied in an 80‑lead low‑profile quad flat package (LQFP).
