The ISL88031 is a five-voltage monitor with industry-leading reset threshold accuracy and low power consumption. The device provides a variety of common features such as power-on reset, undervoltage supply monitoring, reset signaling and manual reset. The ISL88031 uses a small 8-pin MSOP package to monitor up to 5 different voltage levels, which can help reduce system costs, reduce board space requirements and improve system reliability.
The ISL88031 is a five‑voltage monitor IC offered in an 8‑lead MSOP package. It provides five independent voltage reference outputs (Vpp, V2MON, V3MON, V4MON, V5MON) with low quiescent current, making it suitable for power‑management and monitoring applications.
The datasheet includes electrical characteristics, maximum ratings, pin configuration, package dimensions, and typical application circuits, along with an evaluation board description for system integration. This manual is written in Japanese.
| Vpp voltage range | 2.0 V – 5.5 V |
|---|---|
| V2MON typical voltage | 3.3 V |
| Maximum Vpp current | 19 µA |
| Operating temperature range | -40 °C to +125 °C |
| Package type | 8‑lead MSOP |
The device can monitor voltages from 2.0 V up to 5.5 V on the Vpp pin.
It provides five independent monitor outputs: Vpp, V2MON, V3MON, V4MON, and V5MON.
The typical quiescent current is about 19 µA at 5 V supply.
The IC is supplied in an 8‑lead MSOP package.
