The HIP2100 is a high frequency, 100V Half Bridge N-Channel power MOSFET driver IC from Intersil. It features low cost, high frequency, low power consumption, and can drive 1000pF load with rise and fall times typical of 10ns.
The HIP2100 is a high‑frequency, 100 V half‑bridge N‑Channel power MOSFET driver IC. It offers independent low‑side and high‑side gate drivers with 8 ns matching, on‑chip bootstrap diode, and undervoltage protection for both sides.
The device is offered in SOIC, EPSOIC, QFN and DFN packages and is RoHS‑compliant. Typical applications include telecom half‑bridge power supplies, avionics DC‑DC converters, and two‑switch forward converters.
| Supply Voltage Range (Absolute Max) | -0.3 V to 18 V |
|---|---|
| Quiescent Current (Vpp) | 0.1 – 0.2 mA |
| Output Rise/Fall Time (1000 pF load) | 10 ns |
| Available Packages | SOIC, EPSOIC, QFN, DFN |
The absolute maximum supply voltage rating is –0.3 V to 18 V.
The HIP2100 is available in SOIC, EPSOIC, QFN, and DFN packages.
