ISL6801 is a high voltage bootstrap high side driver produced by Intersil. It has two independent output pins that can independently control the rise and fall times.
The ISL6801 is a single monolithic, inverting bootstrap driver designed for N‑Channel power MOSFETs in high‑side configurations. It includes a floating level‑shifter, integrated recharge path, and separate high and low gate‑drive outputs for independent timing control.
The device is supplied in a space‑saving SO‑8 package, operates from a 5 V controller output, and is rated for a bootstrap supply voltage of up to 120 VDC, peak output drive current of 200 mA, and an operating temperature range of –40 °C to 125 °C.
| Bootstrap Supply Max Voltage | 120 VDC |
|---|---|
| Peak Output Drive Current | 200 mA |
| Switching Frequency | 100 kHz |
| Operating Temperature Range | -40 °C to 125 °C |
The device supports a bootstrap supply voltage up to 120 VDC.
It operates from –40 °C to 125 °C.
The peak output drive current is 200 mA.
The switching frequency is guaranteed at 100 kHz.
