X9317 is a low noise, low power, 100 tap digital potentiometer (XDCP™)
The X9317 digitally controlled potentiometer (XDCP™) provides a resistor array of 99 elements and a 3‑wire interface (CS, U/D, INC) to set the wiper position. The wiper can be used as a three‑terminal potentiometer for voltage control or as a two‑terminal variable resistor for current control, and its position can be stored in non‑volatile memory for recall on power‑up.
Key features include 100 wiper tap points, temperature‑compensated resistance, low standby current (<1 pA), and high reliability with 100 k data changes per bit and 100‑year data retention. The device is offered in 8‑lead SOIC, PDIP, TSSOP and MSOP packages and operates from 2.7 V to 5.5 V supply voltage.
| Number of taps | 100 |
|---|---|
| Resistive elements | 99 |
| Supply voltage range | 2.7 V to 5.5 V |
| Standby current | <1 pA |
| Endurance | 100,000 data changes per bit |
| Data retention | 100 years |
| R‑rotac values | 1 kΩ, 10 kΩ, 50 kΩ, 100 kΩ |
| Package options | 8‑lead SOIC, PDIP, TSSOP, MSOP |
| Operating temperature range | -65 °C to +150 °C |
The X9317 provides 100 wiper tap points.
Yes, the wiper position is stored in non‑volatile memory and recalled on power‑up.
The standby current is less than 1 pA.
It is offered in 8‑lead SOIC, PDIP, TSSOP and MSOP packages.
