This is a document about the Philips AE1530 Pocket Radio. The radio features FM and MW waveband selection, tuning capability, and volume control. It is powered by 2 AAA batteries and has improved FM reception with a telescopic antenna.
This manual explains how to set up and operate the Philips AE1530 pocket radio. It covers the controls, battery installation, antenna adjustment, headphone connection, and basic radio reception steps.
Safety guidelines, troubleshooting tips, and maintenance advice are also included to help keep the device functioning safely and reliably.
| Battery type | AAA, R03, UM4 |
|---|---|
| Power supply voltage | 1.5 V |
| Frequency bands | FM, MW |
| Headphone socket | 3.5 mm stereo |
| Antenna type | Telescopic antenna for FM, built‑in antenna for MW |
Open the battery door and insert two alkaline batteries of the same type (AAA, R03 or UM4). Do not mix battery types.
Extend, incline and turn the telescopic antenna for the best FM reception; reduce its length if the signal is too strong.
Turn the OFF VOL control to switch the set on; turn the same control to OFF to switch it off.
Do not expose the set or batteries to humidity, rain, sand, excessive heat, or direct sunlight, and keep ventilation openings clear.
