The AMS6101 is an adjustable step-up DC/DC converter with a 2A internal switch from Advanced Monolithic Systems, Inc. It supports an input voltage as low as 2.7V and an output voltage up to 23V, making it ideal for biasing TFT displays.
The AMS6101 is an adjustable step‑up DC/DC converter featuring a 2 A internal switch and the ability to set the output voltage up to 23 V, making it suitable for biasing TFT displays and other portable applications. It operates at switching frequencies around 600 kHz, allowing easy filtering and low noise, and includes an external compensation pin for flexible frequency control.
The device is supplied in a low‑profile 8‑lead SOIC plastic package and provides over‑temperature protection, shutdown control via the EN pin, and a range of electrical specifications such as a maximum input voltage of 15 V, quiescent current of about 1.3 mA (typical 2.0 mA), and a maximum junction temperature of 150 °C.
| Adjustable output voltage | up to 23 V |
|---|---|
| Switching frequency | 600 kHz (typical, up to 720 kHz) |
| Internal switch current | 2 A |
| Maximum input voltage (VCC) | 15 V |
| Maximum junction temperature | 150 °C |
| Package type | 8‑lead SOIC plastic package |
The device can operate up to 720 kHz, with a typical frequency of 600 kHz.
The converter is shut down by applying a high level to the EN pin.
It is supplied in an 8‑lead SOIC plastic package.
