Featured ROHS manuals
ROHS CIR‑SR46B Camcorder Manual
This manual describes the ROHS CIR‑SR46B infrared half‑ball camcorder, featuring a 13" super‑sensitivity CCD sensor and a 2.8‑11 mm manual zoom lens. The camera offers a diagonal viewing angle of 24°‑97° and is protected to IP65 rating for water resistance.
Key specifications include DC12 V operating voltage, a maximum current draw of 300 mA, dimensions of 120 × 100 mm, weight of 950 g, and operating temperature range of –30 °C to +40 °C. The document also lists accessories, packaging details, and compliance information. This manual is written in Japanese.
Covers: Specifications · Pixel and Video Formats · Power Supply · Physical Dimensions · Operating Conditions · Accessories
CIR-UR85KC Infrared Waterproof Camcorder User Manual
The CIR-UR85KC is a variable‑zoom infrared camcorder designed for outdoor use. It features a 2.8‑11 mm manual zoom lens with automatic aperture, a 1/3" Sony high‑resolution CCD sensor, and an automatic filter‑switching system that eliminates color shift under sunlight or halogen lighting. The camera is rated IP66 for waterproof protection and includes an infrared LED array (76 LEDs) providing a night‑vision range of 20‑25 m.
The device supports dual power options (AC 24 V or DC 12 V) and outputs video at 1 V p‑p. It comes with accessories such as a hex key, positioning paper, and a user manual. Packaging details list a net weight of 1.33 kg and dimensions of 416 mm × 100 mm × 90 mm per unit, with six units per carton. This manual is written in Chinese.
Covers: Specifications · Filter Auto Switch · Lens Details · Power Options · Accessories · Packaging
ROHS WH-CP85WP License Plate Recognition camcorder / Light suppression System camcorder / Speeding capture camcorder Manual
The WH-CP8SWP is a license‑plate recognition, strong‑light suppression, and speed‑capture camera designed for toll stations and parking lots. It features a 1/3" color high‑resolution Sony CCD sensor, 550 TV‑line resolution, and an 8 mm infrared‑compatible lens with a diagonal field of view of 40°.
The manual provides product parameters such as IP66 waterproof rating, DC12 V operating voltage, maximum current 130 mA, dimensions 175 × 100 × 95 mm, weight 900 g, and recommended installation distance of 1.5 m. It also lists included accessories and packaging details. This manual is written in Chinese.
Covers: Product Features · Product Parameters · Technical Specifications · Accessories · Packaging
Latest ROHS manuals
ROHS BPC-8590
Rohs compliant Type 381LQ 105 °C Compact High-Ripple Snap-in 23% Smaller for Same Capacitance
RoHS compliant AMS4122 handbook
ROHS CIR‑SR46B Camcorder Manual
User Manual 2 pages · 199 KB · JAThe ROHS CIR‑SR46B camcorder manual provides specifications, power requirements, and operating details for the infrared half‑ball camera.
CIR-UR85KC Infrared Waterproof Camcorder User Manual
User Manual 2 pages · 207 KB · ZHUser manual with specifications, operation instructions, and accessories for the CIR-UR85KC infrared waterproof camcorder.
ROHS WH-CP85WP License Plate Recognition camcorder / Light suppression System camcorder / Speeding capture camcorder Manual
User Manual 6 pages · 166 KB · ZHUser manual for the WH-CP8SWP license plate recognition camera with specifications, installation guidelines, and accessories.
Rohs power Electricity Sense Manual
Rohs CIR-UR85BC Zoom infrared Anti- water camcorder Manual
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in ROHS manuals
What voltage does the CIR‑SR46B camcorder require?
It operates from a DC12 V power supply.
What is the maximum current consumption of the camera?
The camera draws up to 300 mA under maximum load.
What is the infrared illumination range of the camcorder?
The infrared LEDs provide a night‑vision range of 20 to 25 meters.
What waterproof rating does the camera have?
The camera is rated IP66 for waterproof protection.
What is the waterproof rating of the camera?
The camera has an IP66 waterproof rating.
What is the recommended installation distance for the camera?
The recommended installation distance is 1.5 meters.
