ADN4668 is a 3 V LVDS Quad CMOS differential line receiver with features such as high ESD protection, high-speed data transmission, and low power design. The product is suitable for applications such as point-to-point data transmission, multidrop buses, and clocks.
The ADN4668 is a quad‑channel CMOS low‑voltage differential signaling (LVDS) line receiver. It supports data rates over 400 Mbps (200 MHz), operates from a 3.3 V supply, and consumes only about 3 mW in its quiescent state. The device features a flow‑through pin configuration for easy PCB layout, active‑high and active‑low enable inputs, and 15 kV ESD protection on the receiver pins.
Typical applications include point‑to‑point data transmission, multidrop buses, clock distribution networks and backplane receivers. The part is offered in 16‑lead SOIC and 16‑lead TSSOP packages and is rated for industrial temperatures from –40 °C to +85 °C.
| Maximum data rate | 400 Mbps (200 MHz) |
|---|---|
| Supply voltage | 3.3 V |
| Maximum propagation delay | 2.7 ns |
| ESD protection | 15 kV (human body model) |
| Operating temperature range | –40 °C to +85 °C |
The device supports data rates up to 400 Mbps (200 MHz).
It operates from a 3.3 V power supply.
Typical quiescent current is about 3 mW.
The receiver input pins are protected up to 15 kV (human body model).
