ADN2850 series is a 10-bit dual channel programmable resistor with low temperature drift and non-volatile memory.
The ADN2850 is a dual‑channel, digitally controlled programmable resistor offering 1024 wiper positions per channel. It provides the same adjustment function as a mechanical rheostat with higher resolution, solid‑state reliability, and a low temperature coefficient.
The device includes non‑volatile EEMEM memory that stores wiper settings and actual tolerance values, which are automatically restored on power‑up. Programming is performed via a standard SPI‑compatible serial interface supporting 16 instruction modes, including increment/decrement, log‑taper adjustment, and user‑defined data storage.
| Resolution | 1024 positions per channel |
|---|---|
| Temperature Coefficient | 35 ppm/°C |
| Data Retention | 100 years at 55 °C |
| Package Options | LFCSP‑16 or TSSOP‑16 |
The ADN2850 provides 1024 programmable positions per channel.
Wiper settings are stored in non‑volatile EEMEM memory and automatically restored on power‑on.
