The AD5273 is a 64-position OTP digital potentiometer featuring ultralow power, fast settling time, and a wide temperature range.
The AD5273 is a 64‑position, one‑time programmable (OTP) digital potentiometer that uses fuse‑link technology to permanently set resistance values. It offers a low‑power operation (5 pA max) and a wide temperature range, making it suitable for system calibrations, electronic level settings, and automotive electronics adjustments.
The device is programmed via a 2‑wire I²C‑compatible digital interface and includes validation bits to confirm successful OTP programming. An evaluation kit and Windows‑based programming software are available for factory programming applications.
| Number of positions | 64 |
|---|---|
| Supply voltage range | 2.7 V to 5.5 V |
| Resolution | 6 bits |
| Operating temperature range | -40°C to +105°C |
| Interface | I²C‑compatible 2‑wire digital |
The AD5273 provides 64 programmable positions.
It operates from 2.7 V up to 5.5 V.
It is programmed using a 2‑wire I²C‑compatible digital control interface.
