The AD5025/AD5045/AD5065 are low power, dual 12-/14-/16-bit buffered voltage DACs with various features and functions, suitable for a wide range of applications.
The AD5025/AD5045/AD5065 family are low‑power, dual‑channel nanoDACs offering 12‑, 14‑ or 16‑bit resolution with +1 LSB INL. They operate from a single 4.5 V to 5.5 V supply, feature individual reference pins, rail‑to‑rail outputs, and a high‑speed 3‑wire serial interface compatible with SPI, QSPI and MICROWIRE.
The devices include three selectable power‑down modes, a power‑down lockout pin, and an LDAC function for simultaneous channel updates. Detailed specifications cover static performance, AC characteristics, timing, absolute maximum ratings, and pin functions.
| Supply Voltage (Vop) | 4.5 V to 5.5 V |
|---|---|
| Resolution | AD5065 16 bits, AD5045 14 bits, AD5025 12 bits |
| Relative Accuracy (AD5065) | +0.4 LSB to +1 LSB |
| Power‑down Current | ≈400 nA @5 V |
| Maximum Serial Clock Frequency | 50 MHz |
The devices operate from 4.5 V to 5.5 V.
The serial clock can run up to 50 MHz.
Three power‑down modes are provided for the user.
