AD5541/AD5542 are 2.7 V to 5.5 V, serial-input, voltage-output, 16-bit DACs. The device features full 16-bit performance, 3 V and 5 V single-supply operation, low 0.625 mW power dissipation, 1 μs settling time, unbuffered voltage output capable of driving 60 kΩ loads directly, SPI-/QSPI-/MICROWIRE-compatible interface standards, power-on reset clears DAC output to 0 V (unipolar mode), 5 kV HBM ESD classification and so on.
The AD5541 and AD5542 are single‑supply, 16‑bit voltage‑output DACs with serial‑input interfaces compatible with SPI, QSPI and Microwire. They operate from 2.7 V to 5.5 V and provide unbuffered outputs capable of driving 60 kΩ loads directly. Typical power consumption is low (≈0.6 mW at 5 V) and the devices offer fast settling (≈1 µs) and high accuracy (±1 LSB INL).
The document includes functional block diagrams, pin‑out tables, absolute maximum ratings, timing characteristics, and extensive performance graphs. It also describes bipolar operation for the AD5542, reference‑input configurations, and recommended PCB layout considerations.
| Resolution | 16 Bits |
|---|---|
| Supply Voltage Range | 2.7 V to 5.5 V |
| Typical Power Dissipation | 0.6 mW (5 V supply) |
| Interface Standards | SPI, QSPI, Microwire compatible |
The AD5541 operates from a single supply voltage of 2.7 V to 5.5 V.
Typical power dissipation is about 0.6 mW when powered from 5 V.
The devices support SPI, QSPI, and Microwire compatible serial interfaces.
