The AD5724R/AD5734R/AD5754R is a 12/14/16-bit, single-chip, serial input, unipolar/bipolar voltage output DAC.
The AD5724R, AD5734R, and AD5754R are quad, 12‑/14‑/16‑bit digital‑to‑analog converters with serial input and programmable voltage output ranges. They operate from single or dual supplies (+4.5 V to +16.5 V) and provide integrated reference buffers, power‑up control, and simultaneous updating via LDAC.
The document includes functional block diagrams, detailed electrical specifications, timing diagrams, layout guidelines, and application notes for industrial automation, automotive test, and process control. It also provides ordering information for the 24‑lead TSSOP package.
| Output Voltage Range | -10.8 V to +10.8 V |
|---|---|
| Integral Nonlinearity (INL) | ±16 LSB maximum |
| Differential Nonlinearity (DNL) | ±1 LSB maximum |
| Integrated Reference Accuracy | ±5 ppm/°C maximum |
| Power Dissipation | 310 mW at +16.5 V operation |
| Operating Temperature Range | -40 °C to +85 °C |
The output can swing from -10.8 V to +10.8 V.
The integral nonlinearity is limited to ±16 LSB.
