The AD9216 is a dual, 3 V, 10-bit, 105 MSPS analog-to-digital converter (ADC). It features dual high performance sample-and-hold amplifiers (SHAs) and an integrated voltage reference. The AD9216 uses a multistage differential pipelined architecture, which provides low power, low noise, high dynamic range and excellent crosstalk rejection.
The AD9216 is a dual, 3 V, 10‑bit analog‑to‑digital converter offering up to 105 MSPS sampling rates. It features integrated dual sample‑and‑hold amplifiers, a voltage reference, and supports both differential and single‑ended inputs. The device includes a clock duty‑cycle stabilizer and provides output data in offset binary or two's‑complement format.
Key specifications include a 10‑bit resolution, 57.6 dBc SNR at Nyquist, 74 dBc SFDR, 300 MHz analog bandwidth, and crosstalk better than –80 dB. Power consumption is low at 150 mW per channel at the highest speed grade, and the part is available in a 64‑lead Pb‑free LFCSP package suitable for industrial temperature ranges.
| Maximum Sampling Rate | 105 MSPS |
|---|---|
| Power Consumption (105 MSPS) | 150 mW per channel |
| Signal‑to‑Noise Ratio (Nyquist) | 57.6 dBc |
| Spurious‑Free Dynamic Range (Nyquist) | 74 dBc |
| Analog Bandwidth | 300 MHz |
The AD9216 can operate up to 105 MSPS in its highest‑speed grade.
It consumes about 150 mW per channel at the 105 MSPS speed grade.
The device provides a 300 MHz analog bandwidth.
The signal‑to‑noise ratio is 57.6 dBc at Nyquist.
