The AD9627-11 is a 11-bit, 105 MSPS/150 MSPS, 1.8 V dual analog-to-digital converter. It features low power, high performance, and flexibility, making it ideal for high-frequency communications, radar, and test and measurement applications.
The AD9627-11 is a dual, 11‑bit analog‑to‑digital converter designed for communications applications. It operates from a single 1.8 V supply and supports CMOS or LVDS output levels, with integrated voltage reference, fast‑detect, and signal‑monitor features.
The device is offered in a 64‑lead LFCSP package and is qualified over an industrial temperature range of –40 °C to +85 °C. Detailed specifications, pin configurations, timing diagrams, and a bill of materials are provided for designers.
| Resolution | 11 bits |
|---|---|
| Maximum Sample Rate | 105 MSPS / 150 MSPS |
| Power Consumption (105 MSPS, 1.8 V) | 600 mW – 650 mW |
| Input Voltage Range | 1 V p‑p to 2 V p‑p |
The analog input can accept a signal span of 1 V p‑p to 2 V p‑p.
At 105 MSPS the device consumes between 600 mW and 650 mW.
It is supplied in a 64‑lead LFCSP (Lead‑Frame Chip Scale Package).
The device operates from –40 °C to +85 °C.
