The AD8351 is a low distortion differential RF/IF amplifier with a -3 dB bandwidth of 2.2 GHz. It features single resistor programmable gain, low noise input stage, low harmonic distortion, single-supply operation, low power dissipation, adjustable output common-mode voltage, fast settling and overdrive recovery, etc.
The AD8351 is a low‑cost differential amplifier designed for RF and IF applications up to 2.2 GHz. Its gain can be set from 0 dB to 26 dB with a single external resistor, and it offers a nominal 150 Ω differential output impedance, low noise (2.7 nV/√Hz) and low harmonic distortion.
Typical applications include differential ADC drivers, single‑ended‑to‑differential conversion, IF sampling receivers and RF/IF gain blocks. The device is supplied in a 10‑lead MSOP package and operates from 3 V to 5.5 V over a –40 °C to +85 °C temperature range.
| 3 dB Bandwidth (Ay = 12 dB) | 2.2 GHz |
|---|---|
| Gain Range | 0 dB to 26 dB |
| Supply Voltage | 3 V to 5.5 V |
| Typical Quiescent Current | 28 mA |
| Slew Rate | 13,000 V/µs |
| Input Common‑Mode Voltage Range | 1.2 V to 3.8 V |
The device operates from 3 V to 5.5 V.
Typical quiescent current is 28 mA at a 5 V supply.
Gain can be programmed from 0 dB up to 26 dB using a single external resistor.
At 12 dB gain the 3 dB bandwidth is 2.2 GHz.
