GA-586VX 82430VX motherboard is the upgraded version of GA-586VX, which adds 2 USB ports, supports Quick DRAM Timing, has 2 synchronous DIMM modules, supports 512KB cache, supports Intel P55CT CPU upgrade, supports DIP switch setting.
This manual covers the features and performance of the GA‑586VX PCI‑ISA solution motherboard, including supported CPUs, memory configurations, cache upgrades, and USB ports. It also compares the board's performance with other systems and explains the benefits of its dual‑bank Sync‑DIMM design.
The guide includes detailed installation procedures for various DRAM types, CPU switch settings for Intel, AMD, and Cyrix processors, BIOS default drive tables, and a problem‑sheet for troubleshooting. It provides tables of supported CPU frequencies, memory modules, and hardware specifications.
| CPU | Intel 166 MHz |
|---|---|
| RAM | 8 MB × 2 (total 16 MB) |
| Cache | 256 KB Pipeline Burst SRAM (2 pcs) |
| Cache | 512 KB Pipeline Burst SRAM (4 pcs) |
| Display Adapter | Matrox MGA Millennium |
| Storage | Quantum Fireball 1280 MB |
| Operating System | Windows 95 |
The board supports a range of Intel, AMD, and Cyrix CPUs from 75 MHz up to 200 MHz, with specific switch settings for each processor model.
The motherboard includes two USB ports, available for C&C applications.
The board supports EDO DRAM, FAST PAGE DRAM, and SYNC‑DRAM, with installation guides for one‑bank and two‑bank configurations.
