Foxconn 875A02 Series motherboard user manual, introduces the functions and usage methods of the motherboard
This manual covers the complete setup of the Foxconn 875A02 series motherboard, including unpacking, component checklist, and step‑by‑step installation of the CPU, memory, and expansion cards. It also details BIOS configuration, power‑management options, and special recovery features.
Additional sections describe the bundled utility CD, driver installation procedures for chipset, RAID, USB, and LAN, as well as safety warnings, compliance declarations, and technical specifications of the board.
| Form factor | ATX 12" x 9.6" |
|---|---|
| Supported CPUs | Intel Pentium 4 Socket 478, Intel Celeron Socket 478 |
| Front‑Side Bus | 400 MHz / 533 MHz / 800 MHz |
| Chipset | Intel 875P (NorthBridge) + ICH5R (SouthBridge) |
| Memory slots | Four 184‑pin DDR DIMM sockets |
| USB ports | Eight USB 2.0 ports (four rear, four via headers) |
