This is a PDF product catalog that mainly introduces the detailed information of the DC-DC converters produced by Murata Manufacturing, including input voltage, output power, output voltage, current, efficiency, size, etc.
The PDF is a product catalog from Murata (株式会社村田制作所) that presents a wide range of non‑isolated and isolated DC‑DC converters. For each model it provides key specifications such as input voltage range, output voltage, current capability, efficiency and physical dimensions.
The catalog notes that specifications may change and that some models can be discontinued. Customers are advised to verify the data with Murata sales or engineering representatives before placing an order. This manual is written in Chinese.
| Input voltage range | 2.95 to 3.65 V |
|---|---|
| Output voltage range | 4.5 to 5.5 V |
| Package type | SMD (WAS) or leaded (WAH) |
| Dimensions (example) | 22.1 × 12.6 × 9.1 mm |
Murata offers both SMD type (marked as WAS) and leaded type (marked as WAH) packages.
Yes, the catalog states that specifications may change and discontinued items are not notified; customers should confirm with sales before ordering.
