This manual covers safety warnings, environmental service life (7 years) and basic handling of the TM25/TM29 TV monitors. It includes the packing list, remote‑control details, and connection diagrams.
Detailed operating instructions are provided for power on/off, video input selection, picture adjustments, system and geometry settings, fan control, and de‑gauss functions. The document also lists technical specifications such as screen size, power consumption, and supported video standards. This manual is written in Chinese.
| Supported video standards | NTSC 3.58, NTSC 4.43, PAL |
|---|---|
| Video input signal level | 1.0 Vp‑p |
| S‑video signal level | 1.0 Vp‑p |
| Color signal level | 0.7 Vp‑p |
| Working voltage | 220 V ~ 50 Hz |
| Screen diagonal | TM25 59 cm, TM29 68 cm |
| Dimensions (W×D×H) | TM25 590×553×434 mm, TM29 660×568×542 mm |
| Weight | TM25 ≈ 33 kg, TM29 ≈ 48 kg |
| Power consumption | TM25 70 W, TM29 75 W |
Press the POWER button on the rear panel to turn the unit on; press the "DO" button while the unit is running to turn it off.
If the fan error appears, the unit should be repaired by a qualified service technician.
