This manual introduces the basic operations of TCL TM14/TM15/TM21 series VCRs, including appearance, buttons, function introduction, connection methods, basic operations, AV function, picture adjustment, system settings, and geometry settings.
This manual begins with safety warnings, handling precautions, and an overview of the unit's features, including dimensions, weight, power consumption, and video input options. It also lists the contents of the package and the remote control accessories.
The later sections cover basic operations such as turning the unit on/off, connecting AV sources, adjusting picture settings, system and geometry configurations, and fan control. Detailed menu navigation instructions and parameter explanations are provided for each function. This manual is written in Chinese.
| Dimensions (TM14/TM15) | 390 × 478 × 325 mm |
|---|---|
| Dimensions (TM21) | 504 × 512 × 420 mm |
| Weight (TM14/TM15) | 13 kg |
| Power Consumption | 55 W (TM14/TM15), 60 W (TM21) |
| Input Voltage | 220 V / 50 Hz |
| Video Inputs | AV1, AV2, SVHS |
| Remote Control Power | 2 × AAA batteries |
Press the "ド" button on the POWER switch at the rear panel to power the unit on.
Press the "O" button on the POWER switch while the unit is operating.
The unit provides AV1, AV2, and an SVHS (S‑VIDEO) input jack.
Open the PICTURE menu, select CON (contrast) and use the left/right buttons to change the level.
The fan can be set to VARIABLE, where speed follows temperature, or FIXED, where it runs at maximum speed.
