ABB offers a fast recovery option for its ACS 6000 medium voltage drive to further increase the drive's availability. This option is designed to maintain the DC link voltage level during a main power loss by supplying voltage from an UPS (uninterruptible power supply) to the DC link, thus minimizing the dependency on auxiliary power.
This manual covers the essential information for the ABB ACS 6000 drive, including safety notices, technical data, and wiring guidelines. It is intended for engineers and technicians who install, commission, and maintain the equipment.
Key sections describe power and voltage ratings, communication options such as Profibus, Modbus and DeviceNet, and environmental limits. The document also includes reference tables for IEC compliance and troubleshooting tips.
| Power rating | 3‑27 MW |
|---|---|
| Rated voltage | 3.3 kV |
| Input voltage range | 110‑240 V |
| Frequency | 50 Hz / 60 Hz |
| IEC compliance | IEC 61800‑4, IEC 60146, IEC 60721 |
| Communication protocols | Profibus, Modbus, DeviceNet |
The ACS 6000 is rated for 3 to 27 MW.
It accepts an input voltage between 110 V and 240 V.
The drive supports Profibus, Modbus, and DeviceNet interfaces.
