This quick start guide introduces how to install and program an ATV212 variable frequency drive.
This guide provides step‑by‑step instructions for safely installing and commissioning the ATV212 VFD, including checks of the unit on delivery, line‑voltage compatibility, wiring, and basic parameter setup. It also outlines safety precautions that must be followed before any work on the drive.
The document covers motor‑cable length limits, voltage ranges, and basic menu navigation for configuring motor parameters, acceleration/deceleration ramps, and control modes. References to the full installation and programming manuals are provided for more detailed information. This manual is written in Chinese.
| Maximum motor cable length | <50 m |
|---|---|
| Line voltage range (low) | 200‑240 V 三相 |
| Line voltage range (high) | 380‑480 V 三相 |
| Power rating | 1.5 kW – 2 HP |
| Model variants | ATV212H, ATV212W |
The motor cable length must be less than 50 meters (164 feet).
The drive supports 200‑240 V three‑phase or 380‑480 V three‑phase line voltages.
It is rated at 1.5 kW (approximately 2 HP).
Yes, the guide lists ATV212H and ATV212W as model variants.
