This manual introduces the TCL L22M9/L22M16 high‑resolution LCD television, describing its key functions such as TV and computer display modes, remote control operation, and energy‑saving features. It guides users through safe handling, installation, connection of antennas and external devices, and proper cleaning of the screen.
Additional sections cover troubleshooting common issues, detailed technical specifications, and warranty information, helping users maintain optimal performance and resolve problems quickly. This manual is written in Chinese.
| Model | L22NM9/L22NMI16 |
|---|---|
| Working voltage | 100‑250V~ 50Hz |
| Rated power consumption | 50W |
| Dimensions (package) | 640 mm × 520 mm × 202 mm |
| Weight | 6.5 kg |
| Screen diagonal | 54.8 cm |
| Operating humidity | 20 % – 80 % |
| Storage humidity | 10 % – 90 % |
| TV channel preset capacity | 239 channels (0‑238) |
| Supported TV standards | PAL BG, DK, ... |
| Supported AV standards | Auto, PAL, NTSC |
| Audio outputs | RCA left/right |
The TV can preset 239 channels, numbered 0 to 238.
The rated power consumption is 50 W.
