ViewSonic VP171/VP171b/VP171s LCD display Manual

About this manual

This guide provides instructions for setting up the ViewSonic VP171 17.0" LCD display, including unpacking, connecting video sources, and mounting the unit. It also explains how to switch between horizontal and vertical display modes and how to configure timing settings for optimal image quality.

Safety precautions, compliance information, and troubleshooting tips are included to help users avoid damage to the display and to ensure FCC compliance. The manual also lists the supported video inputs and recommended resolution settings. This manual is written in Japanese.

What's inside

• Safety Information
• Package Contents
• Quick Installation
• Mounting and VESA Compatibility
• Horizontal / Vertical Mode
• Connecting Video Sources
• Setting Timing Mode
• Compliance and FCC Warning

Specifications

Frequently asked questions

How do I switch the display between horizontal and vertical mode?

Place the LCD display face‑down, lift the front panel, rotate the display 90° clockwise, and then re‑attach the panel.

What resolution should I set for the best image quality?

Set the timing mode to 1280 × 1024 at 60 Hz, which is the display’s native resolution.

Which video connectors are supported by the VP171?

The monitor accepts DVI‑D, D‑Sub 1 (VGA) and D‑Sub 2 (VGA) inputs.

What should I do if the monitor causes interference with radio or TV reception?

Re‑orient or relocate the antenna, increase separation between the monitor and the receiver, or plug the monitor into a different circuit.
