TL-WN322G+ 54M USB wireless network card and TL-WN422G+ 54M USB wireless network card are two wireless network cards launched by tp-link company, which support WPA, IEEE 802.1X, TKIP, AES and other security protocols. The maximum transmission speed can reach 54Mbps.
Thank you for purchasing TP-Link wireless USB adapters. The TL-WN322G+ and TL-WN422G+ provide up to 54Mbps data rates, support IEEE 802.11b/g standards, and include security protocols such as WPA, WPA2, WEP, TKIP and AES. TL-WN422G+ features an external high‑gain detachable antenna, while TL-WN322G+ uses an internal antenna.
The manual guides you through hardware installation (direct USB insertion or via the supplied USB extension cable), software installation on Windows operating systems, and usage of the client application. Safety warnings, indicator light behavior, and detailed technical specifications are also included. This manual is written in Chinese.
| Maximum transmission rate | 54Mbps |
|---|---|
| USB interface | USB 2.0 (compatible with USB 1.1) |
| Antenna type | TL-WN422G+: external high‑gain detachable antenna; TL-WN322G+: internal antenna |
| Transmission power (typical) | 13dBm |
| Transmission power (max) | 16dBm |
| Working temperature | 0°C ~ 40°C |
| Storage temperature | -20°C ~ 70°C |
| Working humidity | 10% ~ 90% RH (non‑condensing) |
| Security protocols | WPA, WPA2, WEP (64/128/256‑bit), TKIP, AES |
It supports WPA, WPA2, WEP (64/128/256‑bit), TKIP and AES encryption.
The front status LED flashes when the adapter is powered and has an active wireless connection.
TL‑WN422G+ includes an external high‑gain detachable antenna, while TL‑WN322G+ uses an internal antenna.
