This document provides instructions for using the microcomputer vertical air conditioner and safety regulations, including installation requirements, power cord requirements, moisture and dust protection levels, operating temperature ranges, etc. It also provides detailed information on the functions and usage of the controller.
This manual provides step‑by‑step instructions for installing the straight‑stand air‑conditioner, including required clearances, power‑supply specifications and wiring details. It also explains the controller functions, temperature settings, fan speed options and timer features.
Additional sections cover routine cleaning, filter maintenance, safety precautions, and a troubleshooting guide with common fault symptoms and corrective actions. This manual is written in Japanese.
| Indoor IP rating | IPx0 |
|---|---|
| Outdoor IP rating | IPx4 |
| Operating temperature range | 21°C – 32°C |
| Minimum floor clearance | 75 – 150 cm |
| Minimum obstacle clearance | ≥50 cm |
| Recommended power‑cord cross‑section | ≥3.5 mm² |
| Exhaust airflow | 27 kg/cnY |
| Intake airflow | 6 kg/cnY |
The unit should be installed with a floor clearance of 75 – 150 cm.
The indoor side has an IP rating of IPx0, while the outdoor side is rated IPx4.
The air‑conditioner operates between 21 °C and 32 °C.
