The XE61C series is a highly precise, low power consumption voltage detector, manufactured using CMOS process and laser trimming technologies. Detect voltage is extremely accurate with minimal temperature drift. Both CMOS and N-ch open drain output configurations are available. The XE61C assures all temperature range (Ta= - 40OC ~ + 85OC).
The XE61C series are highly precise, low‑power voltage detector ICs manufactured by Torex. They are offered with CMOS and N‑channel open‑drain output configurations and operate over a wide input voltage range while maintaining accurate detection and minimal temperature drift.
The datasheet provides electrical characteristics, pin assignments for SOT‑23 and SOT‑89 packages, typical performance graphs, marking rules, usage notes, oscillation warnings, and example test circuits.
| Detect Voltage Range | 1.6 V ~ 6.0 V |
|---|---|
| Operating Voltage Range | 0.7 V ~ 10.0 V |
| Output Current | 50 mA |
| Package Types | SOT‑23, SOT‑89 |
| Operating Temperature Range | -40 °C ~ +85 °C |
| Supply Current (typical at VIN=3.0 V) | 3.5 µA |
The detect voltage ranges from 1.6 V to 6.0 V.
Both CMOS output and N‑channel open‑drain output configurations are available.
The device is offered in SOT‑23 and SOT‑89 surface‑mount packages.
The IC operates from –40 °C up to +85 °C.
