Haier KDR-32Q Commercial Air Conditioner Installation Manual

About this manual

This manual provides the safety precautions, required tools, and step‑by‑step procedures for installing the Haier KDR‑32Q indoor unit. It explains grounding requirements, leak‑detector installation, and proper mounting surfaces to prevent accidents such as water leakage or fire.

The guide also details the connection of refrigerant pipes, electrical wiring, and the use of the remote‑control interface. Technical specifications, parts identification, and basic operation instructions are included to help technicians complete the installation correctly. This manual is written in Chinese.

What's inside

• Safety Precautions
• Parts Identification
• Installation Procedure Overview
• Indoor Unit Mounting
• Refrigerant Pipe and Electrical Wiring
• Control Panel and Remote Interface
• Technical Specifications
• Maintenance and Troubleshooting

Specifications

Frequently asked questions

What safety precautions must be observed before installing the unit?

The installer must ensure proper grounding, install a leak detector, avoid mounting on unsupported metal frames, and follow all listed warnings to prevent water leakage, fire or electric shock.

What is the required power supply for the KDR‑32Q?

The unit operates on a single‑phase 220 V, 50 Hz power supply.

What is the cooling capacity of the KDR‑32Q?

The cooling capacity is 3200 W.
