This manual provides the necessary instructions to install the Haier KF(R)-40QW commercial air‑conditioner safely and correctly. It includes safety precautions, required tools, wiring diagrams, and step‑by‑step procedures for mounting indoor and outdoor units.
The guide also describes the main features of the unit, such as cooling/heating capacity, de‑humidification, remote control functions, and optional centralized control. Technical parameters and troubleshooting tips are listed at the end of the document. This manual is written in Chinese.
| Voltage | 1PH 220 V |
|---|---|
| Cooling capacity | 5000 W |
| Power consumption (cooling) | 1950 W |
| Indoor unit noise level | 45 dB(A) |
| Outdoor unit noise level | 58 dB(A) |
| Outdoor unit weight | 59 kg |
The unit operates on single‑phase 220 V power.
It provides a cooling capacity of 5000 W.
Use the remote control to adjust the set temperature; the range is 16 °C to 30 °C.
The indoor unit produces about 45 dB(A) of sound.
