This guide provides the required safety precautions, grounding instructions, and recommended installation locations for the Haier KR-80W (BP) commercial air‑conditioner. It also details the handling of refrigerant lines, pipe sizing, and torque specifications for connections.
The manual includes step‑by‑step procedures for moving, mounting, and connecting the outdoor unit, as well as tables of technical specifications such as cooling capacity, power consumption, and noise levels. This manual is written in Chinese.
| Cooling capacity | 8000W |
|---|---|
| Power supply | 1PH, 220V, 50Hz |
The outdoor unit should be powered for at least 12 hours before starting to protect the compressor.
Effective grounding is mandatory and the ground wire must not be connected to gas pipes, water pipes, lightning rods, or telephone lines.
No, the unit must be installed on a dedicated metal frame; installing on non‑metal structures can cause the unit to fall and cause injury.
The system uses refrigerant R‑22 (IR22).
