This manual explains how to install the indoor and outdoor units, connect the power supply, and perform safety checks before first use. It includes step‑by‑step installation procedures, wiring diagrams, and recommended tools for a correct setup.
The guide also covers operating modes, de‑humidification, heating, and troubleshooting, and lists the performance parameters such as cooling capacity, power consumption, current, noise level and weight of the units. This manual is written in Chinese.
| Model | KFRd-120LWL |
|---|---|
| Cooling capacity | 12000W |
| Heating capacity | 12000W |
| Power consumption | 4700W |
| Rated current | 8.5A |
| De‑humidification capacity | 5.0×10³ mg/h |
| Indoor unit weight | 60 kg |
| Outdoor unit weight | 80 kg |
The air‑conditioner must use a power cable rated 20 A or higher, with a cross‑section of at least 5 × 2.5 mm², and a circuit breaker should be installed in humid locations.
The unit can remove 5.0 × 10³ mg of moisture per hour.
Press the sleep button for 5 seconds, repeat 10 times; the unit will emit four beeps and the stop function will be activated. To cancel, press the button for 5 seconds again, repeat 10 times, and listen for two beeps.
