The manual begins with safety precautions, emphasizing proper grounding, the use of circuit breakers, and the risks of leaks or fire. It then details the installation procedure for indoor and outdoor units, pipe routing, and required tools.
Subsequent sections cover operation guides, control functions, maintenance steps, technical specifications, and a fault‑diagnosis table that explains the meaning of the indicator‑light codes. The document ends with cleaning instructions and parts replacement advice. This manual is written in Chinese.
| Cooling capacity (W) | 2500 / 3200 / 5000 / 7100 |
|---|---|
| Heating capacity (W) | 3000 / 4000 / 6000 / 8000 |
| Water flow rate (L/h) | 288 / 322 / 389 / 645 |
| Power consumption (W) | 60 / 70 / 80 / 190 |
| Sound level (dB(A)) | 40 / 42.6 / 47.6 / 50 |
| Static pressure (MPa) | 30 |
| Maximum pipe length (m) | 50 |
The installer must ensure proper grounding, install a circuit breaker, avoid using non‑specified parts, and prevent water or refrigerant leaks that could cause fire or electric shock.
The refrigerant (or water) pipe can be installed up to 50 meters in length.
