This document is a user manual that provides information on the installation, usage, precautions, and technical specifications of a split air conditioner.
This manual provides step‑by‑step instructions for installing, wiring, and operating the Sampo AM‑series heating and cooling gas machines. It includes safety precautions, grounding requirements, and guidelines for proper pipe length and electrical connections.
The document also describes the functions of each component, explains the photocatalyst air‑cleaning system, and offers troubleshooting tips for remote‑control operation and filter maintenance. This manual is written in Chinese.
| Maximum suction pressure | 6 kg/cm² |
|---|---|
| Hot side temperature range | 21 °C – 43 °C |
| Cold side temperature range | 21 °C – 32 °C |
| Recommended power‑line conductor area | 3.5 mm² or 2.0 mm² |
| Ground wire size | 2.5 mm² – 6.0 mm² |
| Maximum pipe length | 7 m |
For heating, the ambient temperature may be between 21 °C and 43 °C; for cooling, between 21 °C and 32 °C.
The piping length should not exceed 7 meters to ensure proper performance.
Use a green grounding wire with a cross‑section between 2.5 mm² and 6.0 mm².
